Ruthenium coating titanium anode application field:
Non-ferrous metal electrolysis production, chlorine electrolysis, seawater electrolysis, metal foil manufacturing, metal foil surface electrochemical treatment, non-ferrous metal electrolysis extraction and recovery, organic electrolysis, cathodic protection, electrodialysis, acid-base ionized water manufacturing, industrial wastewater treatment and other fields. According to the classification of gas precipitated by electrochemical reaction, the insoluble anode can be divided into: chlorine evolution anodes, oxygen evolution anodes and chlorine evolution anodes. Ruthenium oxide - coated titanium anode belongs to chloride - out type anode.
Ruthenium mixed oxide coating titanium anode product characteristics
Different coating formulations can be prepared according to different use environments. Improved nanoscale grain refinement makes the coating better combined with the substrate, it play the role of electrocatalysis and prolong the service life of the electrode.
2. The anode size is stable and the electrode spacing does not change during the electrolysis process, which can ensure that the electrolysis operation is carried out under the condition of stable cell voltage.
3, reduce chlorine overpotential, good corrosion resistance.
4, low working voltage, small power consumption, can reduce the consumption of about 20%.
5, can improve the current density. For example, in the production of chlor-alkali by diaphragm method, the current density of graphite electrode is 8A/dm2 and the titanium anode can be doubled, up to 17A/dm2. In this way, the output can be doubled under the same condition of the electrolytic workshop and electrolytic cell.
6. The size and shape of the anode can be customized according to the actual working conditions to meet the requirements.
7, According to the anode coating consumption, we can provide anode repair coating technical services to make sure the substrate in the case of no excessive loss, can be used repeatedly and save costs for users.
Product parameters
The following are the conventional parameters. Various specifications can be designed and customized. For specific technical parameters, please contact us sales@firmakes.com


Base Material	Coating	Use Environment	Dimension Specifications	Shape	Service Life
GR1/GR2	Pure ruthenium, ruthenium-iridium, ruthenium-iridium ternary, ruthenium-iridium mixed oxide formula	It is generally used in hydrochloric acid, electrolytic sea water and electrolytic salt water environment	Customize as needed	Plate,       mesh,        tube	Adjustable and               designed

Our products are widely used in electrolysis, PCB, electroplating, chemical industry, environmental protection, water treatment, cathodic protection and other electrolytic anode industrial fields such as: chlor-alkali industry, chlorate production, production of hypochlorite, perchlorate, persulfate electrolysis, electrochemical organic synthesis, production of electrolytic extraction of non-ferrous metal, electrolytic silver catalyst, manufacturing electrolysis copper foil, electrolytic oxidation recycling mercury, electrolysis, chlorine dioxide production, hospital wastewater treatment, electroplating factory bearing cyanide wastewater treatment, water disinfection, power plants and food products cooling circulating water treatment, woolen mill dyeing wastewater treatment, industrial water treatment, electrolysis legal system in acid and alkaline ionized water, copper zinc plated, rhodium, palladium plating, gold plating, plating lead, electrodialysis desalination, electrodialysis method take tetramethyl ammonium hydroxide, molten salt electrolysis, battery production, cathodic protection, in the production of the cathode foil, aluminum foil anodic oxidation, etc.
Our products are exported to more than 30 countries and regions, such as Europe, America, Southeast Asia and the Middle East, etc., and have been well received and confirmed by customers. "Quality first, Customer first" is the company's service objective. We will provide customers with appropriate, environmental protection, economic high quality products.
