MMO Titanium Wire Anode Application Field:
1. It can be used alone as an auxiliary anode for cathodic protection, or used as MMO electrocatalytic electrode for cylindrical anode or flexible anode;
2. It can be used for cathodic protection of continuous horizontal ground bed, discontinuous vertical ground surface, storage tank equipment, cable protection, boiling water container, etc.
3. It can also be used as an auxiliary anode for industrial electroplating and electrocatalytic oxidation electrode for electrochemical water treatment.
MMO Titanium Wire Anode Product Introduction
MMO Titanium Wire Anode, MMO Filamentous Anode, MMO Anode, Titanium Wire Anode
Application Of MMO Titanium Wire Anode
1. The application of MMO titanium anode wire in cathodic protection is basically the same as the use principle and method of titanium anode strip and titanium mesh strip anode.
2. When used in MMO/Ti flexible anode, as MMO anode core, it can make the flexible anode achieve high discharge density and prolong its service life.
3. It can be used in industrial electroplating, as an insoluble auxiliary anode, can also be used as electrolysis hydroelectric catalytic electrode materials.
Product Parameters
| Diameter (mm) Length Can Be Customized |
Coating Layer Types |
Output Current (mA/m) |
Expected Life (years) |
| 1.5 |
Ruthenium-Iridium, Iridium Tantalum, Platinum-Plated |
328 |
20—50 |
| 2 |
Ruthenium-Iridium, Iridium Tantalum, Platinum-Plated |
500 |
20—50 |
| 3 |
Ruthenium-Iridium, Iridium Tantalum, Platinum-Plated |
656 |
20—5 |
Our products are widely used in electrolysis, PCB, electroplating, chemical industry, environmental protection, water treatment, cathodic protection and other electrolytic anode industrial fields such as: chlor-alkali industry, chlorate production, production of hypochlorite, perchlorate, persulfate electrolysis, electrochemical organic synthesis, production of electrolytic extraction of non-ferrous metal, electrolytic silver catalyst, manufacturing electrolysis copper foil, electrolytic oxidation recycling mercury, electrolysis, chlorine dioxide production, hospital wastewater treatment, electroplating factory bearing cyanide wastewater treatment, water disinfection, power plants and food products cooling circulating water treatment, woolen mill dyeing wastewater treatment, industrial water treatment, electrolysis legal system in acid and alkaline ionized water, copper zinc plated, rhodium, palladium plating, gold plating, plating lead, electrodialysis desalination, electrodialysis method take tetramethyl ammonium hydroxide, molten salt electrolysis, battery production, cathodic protection, in the production of the cathode foil, aluminum foil anodic oxidation, etc.
Our products are exported to more than 30 countries and regions, such as Europe, America, Southeast Asia and the Middle East, etc., and have been well received and confirmed by customers. "Quality first, Customer first" is the company's service objective. We will provide customers with appropriate, environmental protection, economic high quality products.
